Operating guide | VACON® NXS/NXP Air-cooled
12.2.3.2 Dimensions for Flange Mounting, FR7-FR8
W4
W2
Illustration 50: Dimensions of the VACON
Table 27: Dimensions in mm (in inch) of the VACON
Drive type
0075 2-0114 2
0072 5-0105 5
0041 6-0052 6
0140 2-0205 2
0140 5-0205 5
0062 6-0100 6
132 | Danfoss A/S © 2018.06
Ø
H6
®
NXS/NXP AC Drive with Flange, FR7 and FR8
®
NXS/NXP AC Drive with Flange, FR7 and FR8, part 1
W1 W2
237 175
(9.33) (6.89)
289 -
(11.38) (-)
H3
W3
W1
IP21
W3 W4
270 253
(10.63) (9.96)
355 330
(13.98) (12.99)
Specifications
H7
W3
W1
IP54
D1 D2
257 117
(10.12) (4.61)
344 110
(13.54) (4.33)
Ø
6.5
(0.26)
9
(0.35)
DPD00910G
