Operating guide | VACON® NXS/NXP Air-cooled
SHOCK HAZARD FROM MULTI-CONDUCTOR CABLES
With a multi-conductor cable, the conductors that are not connected can cause an accidental contact with a conducting
component.
If a multi-conductor cable is used, cut off all conductors that are not connected.
-
The enclosure sizes FR8 and larger have the DC connection as optional.
If it is necessary to connect an external brake resistor, see VACON
Resistor Connection.

6.2 EMC-compliant Installation

For cable selections in different EMC levels, see
To comply with the EMC levels, use a grommet when installing the motor cable at the two ends. For the EMC levels C1 and C2, it is
necessary to have a 360º grounding of the shield with grommets in the motor end.
Table 10: Recommendations for Cables
Cable
Category C1 and C2
type
Motor ca- A symmetrical power cable with a compact low-im-
ble pedance shield.
A cable for the specified mains voltage.
We recommend an NKCABLES /MCCMK, SAB/
ÖZCUY-J or equivalent cable. See
Mains ca- A power cable for a fixed installation.
ble
A cable for the specified mains voltage.
A shielded cable is not necessary.
We recommend an NKCABLES/MCMK cable.
Control A shielded cable with a compact low-impedance shield, for example an NKCABLES/ JAMAK, or an SAB/ÖZCuY-O cable.
cable
1
st
1 environment
2
nd
2 environment
For the definitions of EMC protection levels, see IEC/EN 61800-3 + A1.
Danfoss A/S © 2018.06
C A U T I O N
table 10.
(1)
illustration 14.
®
Brake Resistor Manual. See also
(2)
Category C3 Category C4
A symmetrical power cable with a concentric protection wire.
A cable for the specified mains voltage.
We recommend an NKCABLES/MCMK cable. See
Electrical Installation
8.7.8.2 Setting the Internal Brake
(2)
No EMC protection
illustration
DPD00910G | 41
(2)
14.
