Submenus
Main menu
V1.1 Output frequency
M1 Monitor
V1.2 Frequency ref.
V1.3 Motor speed
V1.4 Motor current
V1.5 Motor torque
V1.6 Motor power
V1.7 Motor voltage
V1.8 DC-link voltage
V1.9 Unit temperature
V1.10 Motor temp.
V1.11 Analogue Input 1
V1.12 Analogue Input 2
V1.13 Current input
V1.14 DIN1, DIN2, DIN3
V1.15 DIN4, DIN5, DIN6
V1.16 Analogue output
V1.17 Multimonit. items
M2
See Application Manual
Parameters
P3.1 Control place
M3 Keypad
control
R3.2 Keypad reference
P3.3
Direction (on keypad)
P3.4 Stop button
Illustration 5: Basic Menu Structure of the AC Drive
Danfoss A/S © 2018.06
Submenus
Main menu
M4 Active
faults
M5 Fault
history
M6 System
S6.1 Language selection
menu
S6.2
Application selection
S6.3 Copy parameters
S6.4 Compare param.
S6.5 Security
S6.6 Keypad settings
S6.7 Hardware settings
S6.8 System information
S6.9 Power monitor
S6.11 Power
multi-monitor
M7 Expand -
er boards
