Operating guide | VACON® NXS/NXP Air-cooled
12.2.2.3 Dimensions for FR8
Ø
W2
Illustration 46: Dimensions of the VACON
Table 22: Dimensions in mm (in inch) of the VACON
Drive type
0140 2-0205 2
0140 5-0205 5
0062 6-0100 6
128 | Danfoss A/S © 2018.06
®
NXS/NXP AC Drive, FR8
®
NXS/NXP AC Drive, FR8
W1 W2
291 255
(11.47) (10.04)
H1
W1
H1 H2
758 732
(29.88) (28.81)
Specifications
E1Ø
D1 Ø
344 9
(13.54) (0.35)
E1Ø
2 x 59
(2 x 2.32)
DPD00910G
