FR5
A Control terminals
C Motor terminals
Illustration 16: FR5 Terminals

6.4.3 Get Access and Locate the Terminals for FR6

Context:
Follow these instructions to open the AC drive for installing the cables, for example.
48 | Danfoss A/S © 2018.06
B C
D
B Brake resistor terminals
Electrical Installation
DPD00910G
