Operating guide | VACON® NXS/NXP Air-cooled

12.5 Tightening Torques for Cover Screws

Enclosure size and class
FR4 IP54
FR5 IP21/ IP54
FR6 IP21/ IP54
FR7 IP21/ IP54
FR8 IP54
FR9
1
The cover of the power unit.

12.6 Tightening Torques of the Terminals

Table 44: Tightening Torques of the Mains and Motor Terminals
Enclosure size Drive type
FR4 0004 2-0012 2
0003 5-0012 5
FR5 0017 2-0031 2
0016 5-0031 5
FR6 0048 2-0061 2
0038 5-0061 5
0004 6-0034 6
FR7 0075 2-0114 2
0072 5-0105 5
0041 6-0052 6
FR8 0168 2-0205 2
0168 5-0205 5
FR9 0261 2-0300 2
0261 5-0300 5
0125 6-0208 6
146 | Danfoss A/S © 2018.06
Cable cover screws (Nm)
2.2
2.2
2.2
2.4
0.8 Nm (1)
0.8
Tightening torque (Nm)
0.5–0.6
1.2–1.5
10
10
40
40
Screws on the cover of the AC drive (Nm)
0.7
0.7
0.7
0.8
0.8
0.8
Tightening torque (lb-in.)
4.5–5.3
10.6–13.3
88.5
88.5
354
354
Specifications
DPD00910G
