Toshiba e-STUDIO477S Service Manual page 383

e-STUDIO477S/527S
05/08 Mode Element Sub Element
08 Setting System User interface
mode
08 Setting System User interface
mode
08 Setting System User interface
mode
08 Setting System User interface
mode
08 Setting System User interface
mode
08 Setting System User interface
mode
08 Setting System notification
mode
08 Setting System eAPI
mode Application
08 Setting System eAPI
mode Application
08 Setting System Network
mode
08 Setting System Network
mode
08 Setting System Network
mode
08 Setting System User control
mode
08 Setting System User control
mode
08 Setting System User interface
mode
08 Setting System Maintenance
mode
08 Setting Mode
Item Subitem Code
Paper feeding 8548
Counter 8549
Manual change 8558
of the standard
size
Manual change 8558
of the standard
size
Manual change 8558
of the standard
size
Manual change 8558
of the standard
size
Quota 8567
8568
8569
8585
8586
8587
LDAP Attribute value 8592
authentication setting
LDAP Attribute value 8593
authentication setting
8597
8598
Sub- Default
Details
Code value
Operation of drawer size 0
change when printing is
interrupted by size mismatch
Hardware key control when 0
external counter is installed
0 1st drawer 0
1 2nd drawer 0
2 3rd drawer 0
3 4th drawer 0
near empty 0
Authentication time-out 30
Error sound when an event 0
generated by a card does
not reach
Edit setting of e-mail subject 1
Addition of date and time to 1
email subject
Character string of email 0
subject
Sender address mail
Sender name uid
Automatic update of 0
private/hold print job list
Template icon layout on the 0
control panel
30
Acceptable
RAM Contents
value
0~1 SYS 0: Operation of cassette size change is disabled.
1: Operation of cassette size change is enabled.
0~1 SYS 0: No control
1: Mode switch key is disabled.
0~1 SYS 0:Manual
1:Auto
0~1 SYS 0:Manual
1:Auto
0~1 SYS 0:Manual
1:Auto
0~1 SYS 0:Manual
1:Auto
0~10000 SYS Sets the number of print pages to notify that the
Quota has been nearly reached when it has been
selected.
0: Not notified
1 to 10000: Notified when printed pages reach the
set number
1~180 SYS Sets the time-out period when authentication is
performed by an external application.
(Unit: seconds)
0~1 SYS 0: OFF (not sounded)
1: ON (sounded)
0~1 SYS 0: Not allowed
1: Allowed
0~1 SYS 0: Not added
1: Added
0~1 SYS Switches the default character string of subject.
0: Character string at the shipment
1: Character string specified by users
SYS Sets the default attribute value of sender address.
Maximum 34 characters (ASCII).
SYS Sets the default attribute value of sender name.
Maximum 34 characters (ASCII).
0~1 SYS 0: Disabled
1: Enabled
0~1 SYS 0: Pattern 1
(1) (2) (3) (4)
(5) (6) (7) (8)
(9) (10) (11) (12)
(13) (14) (15) (16)
1: Pattern 2
(1) (2) (9) (10)
(3) (4) (11) (12)
(5) (6) (13) (14)
(7) (8) (15) (16)
Proc
ServiceUI
edure
1
1
4
4
4
4
1
1
1
1
1
1
11
11
1
1
Ver03
