SECTION 9: CLEANING & MAINTENANCE
Cleaning the Optics
Allow the optics to dry before you operate your engraver.
When reinstalling the lens assembly, make sure that the Crash Bar is sitting on top of the locating pins on the side of the
carriage.
Mirror
Focus Lens
In addition to the focus lens and the mirror directly above it, there is a mirror located on the left side of the X-beam. This
mirror is very well protected and should not need regular cleaning. It can be accessed with a cotton swab if it does need
cleaning.
The photos below shows how to clean the focus lens. Remove the lens carriage from the machine to clean both the top
and bottom of this lens.
- 86 -
