Epilog Fusion M2 32 Manual page 155

SECTION 11: OPTIONAL FEATURES
7. Select your laser in the driver list. Make sure this
has the name Epilog in the driver, or move back to
step one. Next close the print window by clicking the
red X.
8. Close PLP, then reopen the software and you are
ready to start using the software.
PhotoLaser Plus Photograph
Transformation
When you first open PLP, your first step is to set your
plate size, which is your page size. You can set this to
match the material you are engraving, or the size of
the engraving table.
Import your photo to be transformed. Select File
then Import.
If the file looks bitmapped after the import, select
View then Show Reduced Bitmaps to see the higher
resolution version of the image.
9. Crop the Photo: If you do not want to engrave the
entire photo, double click on the photo to open the
bitmap tools at the top of the page. Select the
Rectangle or Ellipse tool to frame the area you want
to crop. With the proper area framed, press the Crop
key to finalize the crop.
- 149 -
PhotoLaser Plus
