SECTION 6: USING THE EPILOG MAC DRIVER
Mac Driver Settings
an alternative set of speed parameters that are ½ the speed of the standard settings. Speed Comp mode will most often be
used with speed settings below 10 when very slow cutting is desired. Most users will rarely use Speed Comp mode, but
it adds additional functionality for unusual or demanding applications.
Power Comp: When checked, power compensation reduces the laser output when the laser carriage slows as it moves
through a curve. Selecting Power Comp is especially useful for vector cutting jobs that incorporate a large number of
curves. This has the effect of producing unparalleled edge quality when cutting curves. Most users find that keeping Power
Comp selected is the preferred setting.
Resolution
5
Set your print resolution from 75 to 1200 DPI. For the best engraving results, use a resolution equal to the resolution in
the raster images within your project setup. The resolution setting in the print driver will affect the engraving time (there
are twice as many engraved lines at 600 DPI as at 300 DPI) and the quality. For a detailed discussion, visit "Resolution"
on page 79.
