SECTION 5: USING THE LASER DASHBOARD™
Select Stamp to enable stamp
mode options.
Shoulders: Adjusts the angle
of the sides of the stamp.
Widening: Adjusts the
boldness of the character.
Mirror: Inverts the artwork.
Fence: Defines outer borders.

Update Firmware

3
When you are ready to update your Fusion firmware, click here and load the file. For more information, visit "Section :
Upgrading the Operational Firmware" on page 155.
Configurations
The Configurations feature is a comprehensive data management tool that is used to save all of your Dashboard
4
settings for individual jobs. Saving the Dashboard settings as a database file allows you to retrieve the job parameters
at a later time. This saves you the trouble of trying to remember what speed and power and other settings you used on a
job you did three months ago. All of your settings can all be stored as a permanent record.
For example, in this database we have settings for acrylic, coated steel, glass, and many more. After each configuration file
name, you can see if the saved settings are for a Raster, Vector or Combined job, the resolution, and the piece size within
that file. To use any of these settings, click the Load key.
If you find a setting you would like to save into a new configuration file, simply create the settings within the three Laser
Dashboard tabs, then click Save.
The Driver Disc has a number of preset configuration files available. When you unzip your selected wattage's configuration
files, they will save to c:/epilog/engraving setting. This is the default folder that the Laser Dashboard will look in to load
files available for your laser. After you have found the configuration files you want to use, click on the General tab to see
the settings that the loaded file brings up.
- 55 -
