SECTION 7: FUSION CONTROL PANEL
• Left (Set): Tilt the Joystick to the left to set a new or temporary z-axis Home Position.
Note: The SET 0 function is only used to set or reset a new or temporary Home Position for your table
height when using the Color Mapping function in the Dashboard driver. Auto Focus will not work
properly once a new 0 (zero) table Home Position has been established.
When you set a new 0 (Zero) position for your table, the Auto Focus function in the driver will no longer reference
the default table height. It will reference the new Table Home Position, rendering Auto Focus useless.
You must RESTORE Table Home to re-establish the default Table Home Position if you want to start using Auto
Focus again.
• Right (Restore): Tilt the Joystick to the right to restore the table height to its default Home Position. This is normally
done when you are finished with your new or temporary Table Home Position and want the table to move back to its
default Home Position so you can start using Auto Focus again.
Note: An alternative method of setting a new Table Home Position is to just center click once while in the
Focus Menu. There is no visual indicator on the display, but a single center click after you have focused your
table eliminates double center clicking to access the sub-menu.
JOG
The Jog function allows you to move the laser head around the table with the use of the Joystick. To make it easier to
use, turn on the Red Dot Pointer for a visual indicator of where the carriage is moving. The carriage can be moved in X,
Y or diagonally. The display will show a digital readout of the carriage position.
Jog Sub-Menu: Setting a New X/Y Axis Home Position
The Jog function is most useful for setting a new or temporary Home Position when working on odd shaped items or if it's
just more convenient to designate somewhere other than the upper left corner of the table as your starting point. To set a
new Home Position, use the following instructions:
1. Go to the Jog function on the Control Panel.
2. Use the Joystick to move the carriage to a new position. Use the Red Dot Pointer as a visual indicator of the
carriage location. The display will also show a digital readout of the X and Y position.
3. Double center click to access the sub-menu:
• Up (Go): Tilt the Joystick up to move the carriage back to its zero/zero position. This function will move the lens
carriage back to a new or temporary Home Position.
• Down (Exit): Tilt the Joystick down to exit the sub-menu. Center clicking does the same thing.
