SECTION 2: GETTING STARTED
will need one computer for each laser system.
2. Ethernet only connection: With an Ethernet connection you can print from the Laser Dashboard and use the Epilog
Job Manager.
3. If you are using the optional eView Camera Module, you will need to use both USB and Ethernet connection. For
this connection, please see "Attaching the eView Camera System to Your Computer" on page 135.
USB Connection
A USB cable is included in the accessory kit. The USB port is located at
the rear of the machine. USB cables have different connectors on each
end. Before plugging in the USB cable, turn the laser OFF, then connect
one end to the laser and connect the other end into any available USB port
on your computer. After connecting the USB cable, turn the laser back on.
The computer will recognize a new USB device and walk you through the print driver installation. For detailed instructions,
see "Windows 8 and 10: USB Installation" on page 28.
Ethernet Connection
The Ethernet Port is a standard 10BaseT connection. Your Epilog Laser has all of the versatility of a network capable
peripheral. As such, there are many different ways that the laser can be connected to a computer or a network. A direct
connection using a crossover cable is the only method that will be described in this manual. Connect the crossover cable
(included in the accessories kit) to the Ethernet port, located at the back of the machine. Plug the cable into the Ethernet
port on the laser, then plug the other end into the Ethernet port on your computer.
The Epilog Dashboard is the print driver that allows your computer to talk to your Epilog Laser system when either the USB
or Ethernet Crossover cables are connected. The driver is included in the accessories kit on a CD-ROM or on our website
at www.epiloglaser.com. To see detailed instructions on installing the print driver, see "Windows 8 and 10: Ethernet
Installation" on page 25.

7. Set the Fusion's IP Address

1. To set the IP Address from the Fusion's control panel, press the down
arrow until Settings/Config is selected. It'll vary depending if you have the
symbolic or text keypad.
2. Tilt the joystick down until IP Address appears.
3. Center click to gain access, tilt the Joystick up or down to increment or
decrement. Tilt left or right to move to the different sets of three numbers.
Press the Go key to make your change permanent.
Connect to the laser.
