Epilog Fusion M2 32 Manual page 160

SECTION 11: OPTIONAL FEATURES
9. After clicking OK, the text substitution box will open
allowing you to enter or adjust the names for your
badges.
10. After clicking OK, you will be taken back to your
drawing page and badges will be properly laid out
and populated. You can see that we have ten badges.
One was left blank intentionally because we had ten
badges and only nine names. You're ready to print
your badges to the laser!
Troubleshooting Badge Layout
Problem: The logo doesn't appear on the badges.
Solution: In step 6, you didn't select everything on the
badges before clicking the Badge tool.
Problem: The word Name is repeated on all of the
badges.
Solution: In the badge setup parameters you didn't
highlight Name as the field to replace.
- 154 -
PhotoLaser Plus
