Epilog Fusion M2 32 Manual page 200

APPENDIX B: MATERIAL SETTINGS
Fusion Series Suggested Material Settings (CO2)
Material
Marble
Photo Engraving
Text Engraving
Every marble is very different for settings. Start low and increase the power with a second run if you haven't used that marble before.
Painted Brass
Engraving
Engraving
Plastics
Engraving
These settings work well with many plastics, including plastic phones and covers. Even one color plastics can achieve a great look when engraved.
Plastic (2 Layer Laser Engraveable)
Engraving
Engraving
Cutting 1/16" (1.5 mm)
Rubber Stamps
Engraving
Cutting
Stainless Steel w/Cermark
Engraving
Twill
Cutting
Wood
Photo Engraving
Clipart/Text Engraving
Clipart/Text Engraving
Deep Engraving
Thin Veneer (Cutting)
Cutting 1/8" (3 mm)
Cutting 1/4" (6 mm)
Cutting 3/8" (9.5 mm)
Cutting 1/2" (12 mm)
When cutting wood, multiple passes may allow cutting of thicker materials. Using Color Mapping you can adjust the focus point between passes down to the
center point of the cut for the best results.
* The Fusion has two sets of Speed control for vector cutting applications. Checking the Speed Comp selection box in the print driver will reduce the speed
setting you have selected by one half. Speed Comp is most useful for speeds of 1 to 10. Example: Cut a square at 5% speed. Then repeat the job at 5% speed
and also select Speed Comp. The second square will take twice as long to cut as the first square. Speed Comp gives you more slower speed setting to work
with. Always use Air Assist when cutting.
DPI/Freq. 30 watt
300 DPI 90s 55p
600 DPI 90s 65p
300 DPI 90s 45p
600 DPI 90s 40p
300 DPI 90s 40p
300 DPI 90s 80p
600 DPI 90s 75p
100 f 10s 85p
600 DPI 15s 100p
100 f 5s 100p
600 DPI 20s 100p
25 f 50s 40p
600 DPI 30s 100p
300 DPI 20s 100p
600 DPI 25s 100p
600 DPI 5s 100p
10 f 30s 100p
10 f 3s 100p
10 f 3s* 100p
10 f
10 f
Fusion Series Suggested Material Settings (CO2)
40 watt 50 watt
90s 50p 90s 45p
90s 60p 90s 55p
90s 40p 90s 35p
90s 35p 90s 30p
90s 35p 90s 30p
90s 75p 90s 70p
90s 65p 90s 50p
10s 75p 10s 65p
20s 100p 30s 100p
10s 100p 15s 100p
25s 100p 30s 100p
50s 35p 70s 100p
40s 100p 50s 100p
30s 100p 40s 100p
35s 100p 45s 100p
10s 100p 20s 100p
30s 80p 40s 100p
6s 100p 8s 100p
1s 100p 2s 100p
2s* 100p
- 194 -
60 watt 75 watt
90s 40p 90s 35p
90s 50p 90s 45p
90s 30p 90s 25p
90s 25p 90s 15p
90s 25p 90s 20p
90s 65p 90s 40p
90s 35p 90s 25p
10s 55p 10s 40p
40s 100p 60s 100p
20s 100p 25s 100p
35s 100p 45s 100p
90s 100p 90s 80p
60s 100p 70s 100p
50s 100p 60s 100p
55s 100p 65s 100p
25s 100p 30s 100p
40s 90p 50s 80p
10s 100p 20s 100p
3s 100p 5s 100p
3s* 100p 1s 100p
120 watt
90s 25p
90s 35p
90s 15p
90s 10p
90s 15p
90s 35p
90s 20p
20s 40p
80s 100p
30s 100p
55s 100p
90s 60p
100s 100p
90s 100p
85s 100p
60s 100p
50s 60p
40s 100p
12s 100p
8s 100p
3s 100p
