SECTION 10: SYSTEM FEATURES
To enter the material thickness of the object you will be engraving/marking/cutting use a pair of calipers for an accurate
Please be careful when Auto Focusing on irregularly shaped items. The crash bar and Air Assist tube must
clear all edges of the work piece in this situation also. The Crash Bar is a safety feature that prevents the table
from moving up too far into the lens carriage and X-beam.
Crash Bar
The Crash Bar is mounted to the lens assembly and prevents the table from "crashing" into the X-beam when the table is
moving to its focus position. If the table moves up into the crash bar the system will come to a complete stop and the table
will automatically lower two inches.
If the crash bar is activated, press the Reset key on the front Control Panel to restore functionality.
The crash bar is removed as part of the lens assembly. When reinstalling the lens assembly, please make sure that the
Crash Bar is sitting on top of the locating pins on the side of the carriage.
measurement and enter this value in the
"Thickness" box in the driver.
carriage and your material, you will need to lower
the table before you insert your material and start
the job. To lower the table, use the Arrow keys on
Crash Bar
the Control Panel to illuminate the light next to the
word "Focus". Then use the Joystick to lower the
table enough to accommodate your part.
- 95 -
WARNING: If you are using Auto
Focus and you know there is not
enough clearance between the lens
Crash Bar and
Locating Pins
Crash Bar
