SECTION 2: GETTING STARTED

2. Choose Where to Locate the System

Cooling Requirements and Operating Temperatures
All Epilog Laser systems use air-cooled laser tubes. Laser technology is such that the laser tubes generate a lot of excess
heat and the tubes must be cooled for proper operation. There are cooling fans located at the back of the laser. The fans
and vents should always be clear of restrictions and should never be covered.
Laser Tube Air Filter is a standard 12" x 20"
x 1" (304 x 762 x 25 mm) furnace filter and
can be found at any home store. This is more
likely to need to be changed in a dustier shop
environment.
Warning: The cooling fans and vents are located at the back of the Fusion and should never be covered
or blocked in any way. Lasers that overheat will not operate properly and may begin to produce erratic
laser output or possibly complete failure.
Ambient air temperature where the laser system is operating should not exceed 90 degrees F (32 C). Operating in an
environment where the ambient air temperature is above 90 degrees F (32 C) will void the Epilog warranty.
Cooling Fans
- 12 -
