SECTION 15: SPECIFICATIONS

Fusion Laser Technical Specifications

Fusion M2 32 (CO2)
Maximum 32" x 20" (812 x 508 mm)
Engraving Area
Max Material 13.5 (342 mm) (2" lens)
Thickness
Dual Source 12.5" (317.5 mm) (3" lens)
Laser Source 30, 40, 50, 60, 75 or 120
Wattages watt, CO2, air-cooled,
all-metal tube, 10.6
micrometers.
Standard Features Radiance High Definition Optics (CO2), Air Assist, Red Dot Pointer, relocatable Home Position, LED lighting, integrated floor
stand, brushless servo motors, Super-Silent Cooling Fans, Joystick controls, removable exhaust plenum.
Dual Source Fusion M2: Available with combination of 50, 60 or 75 watt CO2 and 20, 30 or 50 watt Fiber.
Intelligent Memory Store unlimited files up to 128 MB. Rolling buffer allows files of any size.
Buffer
Operating Modes Optimized raster, vector and combined modes.
Motion Control High-speed, continuous-loop, brushless DC servomotors using rotary encoding technology for precise positioning.
System
X-axis Bearings Ground and polished, stainless steel, Teflon coated, self-lubricating bearings.
Belts Advanced B-style Kevlar belts (X-axis) and steel cord (y-axis).
Resolution User controlled from 75 to 1200 DPI.
Speed and Power Computer controlled speed and power in 1% increments to 100%. Color mapping links speed, power, frequency, focus, and
Control (engraving raster/vector mode settings to any RGB color.
depth)
Print Interface 10Base-T Ethernet or USB connection. Compatible with Windows XP/Vista/7/8/10 and Mac OS X 10.7 and up.
Size (W x D x H) 52.5" x 35.5" x 40.75"
(1334 x 851 x 1035 mm)
34.25" (870 mm) deep with Exhaust Plenum
Weight 500 lbs (227 kg)
Dual Source: 536 lbs (243 kg)
Electrical Auto-switching 110 to 240 volts, 50 or 60 Hz, single phase, 15 amp AC.
Requirements
Ventilation Systems 650 CFM (1104 m3/hr) external exhaust to the outside or internal filtration unit is required. There are two output ports, 4"
(102 mm) in diameter.
Laser System Class 2 Laser Product - 1 mW CW MAXIMUM 600-700 nm.
Classification
Technical specifications and product configurations subject to change without notice.
Fusion M2 32 (Fiber)
10.5" (266 mm) (3" lens)
20, 30 or 50 watt, Fiber
Laser. Air cooled, includes
collimator. 1064 nm. Beam
quality: M2 < 1.1.
500 lbs (227 kg)
- 179 -
Fusion Laser Technical Specifications
Fusion M2 40 (CO2)
40" x 28" (1016 x 711 mm)
13.25" (336 mm) (2" lens)
Dual Source 12.25" (311 mm) (3" lens)
30, 40, 50, 60, 75 or 120
watt, CO2, air-cooled,
all-metal tube, 10.6
micrometers.
60.5" x 41.25" x 42.25"
(1537 x 1048 x 1073 mm)
43" (1092 mm) deep with Exhaust Plenum
643 lbs. (292 kg)
Dual Source: 679 lbs (307 kg)
Fusion M2 40 (Fiber)
10.25" (260 mm) (3" lens)
20, 30 or 50 watt, Fiber
Laser. Air cooled, includes
collimator. 1064 nm. Beam
quality: M2 < 1.1.
643 lbs. (292 kg)
