SECTION 7: FUSION CONTROL PANEL
Pointer
The Pointer key is a toggle switch that turns the laser system's Red Dot Pointer on and off. When the Red Dot Pointer is on, the
indicator light directly to the left of the pointer key will be illuminated. For more information visit "Red Dot Pointer" on page 104.
Laser On
The Laser On key allows you to move the carriage and fire the laser without having a job in the display. This is a very handy
feature because it allows you to do simple tasks without printing a job to the laser system.
To use the Laser On feature you must be in Jog mode, with the door closed. When in Jog mode, press and hold the white
Laser On key. Simultaneously use the Joystick to move the carriage. When the carriage moves, the laser will fire. As soon
as the carriage stops moving the laser will stop firing.
You can adjust the default laser power being used in Laser On mode from the Settings menu. Highlight Settings, then use
the Joystick to scroll down to Jog Laser PWR. Center click the Joystick and then tilt the Joystick Up or Down to change
the value. Press the Go key to activate the change. Go back to Jog mode to use Laser On.
Job
• The Jobs selection allows you to use the Joystick to scroll through the jobs in your laser system. You will be able
to see the job in the first line of the display. The estimated job time and the print resolution will also show on the
second line of the display.
• The job name displayed is the same name as the file name that you printed to the laser.
• When the job you want has been selected, press the Go key in the action keys to start the job.
• After the job starts, the job timer in will be activated and will be shown on the second line of the display.
