SECTION 6: USING THE EPILOG MAC DRIVER
6. You will return to this print window, so click Print.
7. The driver will now transfer the job to the Epilog
Viewer. The Epilog Transfer icon will appear in the
Dock. The transfer will take several seconds.
8. Once the Epilog Transfer Icon disappears, the Epilog
Viewer Icon will bounce up and down and you can
click on the icon to access the Epilog Viewer.
It's important that the Epilog Viewer is open
before printing. If it is not open, pause the
transfer in the processing window, open the
Epilog Viewer, and restart the transfer.
9. In the Epilog Viewer, click Edit Settings if you want
to change any print settings, or click Print if the job
is ready to send to the laser.

Vector Cutting Lines

1. Unlike Windows, the Mac Driver allows you to set
the line width that will be cut in the driver. For this
file we have some lines that will be engraved and
some that will be cut. The cut lines we set to 0.23
pixels, while the engraved lines we set to 1 pixel
width.
2. At the bottom right corner of the screen type .3 in
the Vector Less Than box. This will cut any line that
is less than .3 pixels in width and engrave any
above that amount.
- 63 -
