SECTION 11: OPTIONAL FEATURES
5. Set the resolution to match your engraving
resolution. This is usually 300 or 600 DPi. Set the
color mode to either RGB, CMYK, or Grayscale (it
doesn't matter which one).
6. Copy the photo in Corel by selecting Edit, then Copy.
7. Open PLP and paste the image anywhere on the
page by selecting Edit, then Paste.
8. Transform the photo by following steps 6 through 9
in the previous section.
9. After the transformed image is prepared, select File
then Export Image. Export the file as a .bmp. Make
note of where you saved the transformed file.
10. In CorelDRAW select File then Import and select
your transformed file. Place the photo in the
designated space without resizing the image.
11. Print the file from CorelDRAW as you normally
would, using the same resolution that you selected
in step 5.
Creating Badges with Variable
Names
Another feature of PhotoLaser Plus is it's flexible badge
layout function. We'll show you how to setup multiple
items, such as badges, on one page with different names
on each badge.
1. Start by opening a new file and setting the plate
size to the equivalent of one badge. 3" x 1" in this
example.
2. Setup the badge by importing any images.
3. For the variable name, go to the Text tool and select
the second option, the Text Compose tool (this tool
allows you to auto condense long names).
- 152 -
PhotoLaser Plus
