SECTION 7: FUSION CONTROL PANEL
10. Serial #: This establishes a serial number for USB use. Center click to gain access, tilt the Joystick up or down to
increment or decrement. Press the Go key to make your change permanent. This function is rarely used.
11. IP Address: This sets the IP Address of the laser system. Center click to gain access, tilt the Joystick up or down
to increment or decrement. Tilt left or right to move to the different sets of three numbers. Press the Go key to
make your change permanent.
12. Subnet Mask: This sets the Subnet mask for the laser system. Center click to gain access, tilt the Joystick up or
down to increment or decrement. Tilt left or right to move to the different sets of three numbers. Press the Go key
to make your change permanent.
13. Gateway: This sets the Gateway for the laser system. Center click to gain access, tilt the Joystick up or down to
increment or decrement. Tilt left or right to move to the different sets of three numbers. Press the Go key to make
your change permanent.
14. Laser Installed: This is a factory setting that is not user accessible and shows which type laser is installed in the
machine - CO2, Fiber, or both. CO2 lasers are the most versatile and work with many different types of materials.
Fiber lasers are used for metal marking only.
15. Vector Grid In: This indicates if the Vector Cutting Table is installed. Center click to gain access, tilt the Joystick up
or down to toggle between Yes and No. Press the Go key to make your change permanent.
16. AirA Raster: This tells the machine to activate Air Assist during all Raster jobs. Center click to gain access, tilt the
Joystick up or down to toggle between Yes and No. Press the Go key to make your change permanent.
17. AirA Vector: This tells the machine to activate Air Assist during all Vector jobs. Center click to gain access, tilt the
Joystick up or down to toggle between Yes and No. Press the Go key to make your change permanent.
18. CO2 Laser Match: This sets the left-right raster line alignment for the CO2 laser. This setting is normally a factory
only setting and will not need to be adjusted by the user.
19. Fiber Laser Match: This sets the left-right raster line alignment for the fiber laser. This setting is normally a factory
only setting and will not need to be adjusted by the user.
♦
20. Set XY Home: This sets a new Home Position. Most users find it is easier to make this setting from the sub-
menu in Jog mode.
♦
21. Set Table Home: This sets a new Table Home Position. Most users find it is easier to make this setting from the
sub-menu in Focus mode.
♦
22. Go XY Home: This restores the carriage lens to its default Home Position in the upper left corner of the machine.
Most users find it is easier to make this setting from the sub-menu in Jog mode.
23. Auto Delete: This setting allows you to have jobs automatically delete after running. You will typically want to have
this setting turned to No.
♦
24. Go Table Home: This restores the table to its default Home Position.
25. X Scale Adjust: This setting calibrates the accuracy in the X-axis. This setting is normally a factory only setting and
will not need to be adjusted by the user.
26. Y Scale Adjust: This setting calibrates the accuracy in the Y-axis. This setting is normally a factory only setting and
will not need to be adjusted by the user.
