Snmp - Polycom RSS 4000 User Manual

Polycom RSS 4000 System User Guide

SNMP

42
To configure the SIP settings:
Go to System Config > Signaling Settings > SIP.
1
Configure the following settings:
2
Parameter
Enable SIP
Transport Type
Enable Certificate
Validation
Register to SIP Server
Register to Microsoft Lync
Server 2010
SIP Server
Register User Information
Outbound Proxy Server
Click Update. The system restarts to apply your changes.
3
Your system provides a standard SNMP (Simple Network Management
Protocol) interface which supports SNMP version 1, version 2, and version 3
queries with confidentiality, authentication, and integrity functions
conforming to SNMP MIB. The interface uses a common MIB, making it
interoperable with Polycom CMA, DMA, and RMX systems.
Description
Specify whether to enable the SIP in the system. You need
to set the SIP server-related parameters after this function is
enabled.
Specify the transport layer protocol used for
communicating with the SIP server. It needs to be
consistent with the protocol supported by the SIP server.
Specify whether to validate the server's certificate before
accepting it.
This option is available only after you select TLS as the
Transport Type.
Note: The RSS system always sends its own certificate to
the server, regardless of the selection here.
Specify whether to register the system to the SIP server.
Specify whether to register the system to the Microsoft
Lync Server 2010.
Specify the IP address, connection port, and domain name
of the SIP server for registration service.
Specify the user name and password that authenticates the
system to the SIP Server.
For communication with the SIP server when the system is
configured on the internal network, an outbound proxy
server is required to implement traversal of the firewall or
NAT. In this case, you need to set the IP address and port
number for the outbound proxy server.
System Configuration
Polycom, Inc.
