Polycom RSS 4000 User Manual page 87

External Servers
Polycom, Inc.
Parameter Description
Password Specify your password to access this FTP server.
Default Path Specify the default FTP directory to save your recordings.
Use / to represent the root directory.
Enable SSL Specify whether to enable SSL encryption for the
communication between the Polycom RSS 4000 system and the
FTP server.
Click OK.
7
• When Video on Demand is enabled, the Polycom RSS system transfers all available
media files (MP4, MP3, and WMV) to the specified FTP server. However, only MP4
and WMV files are playable as the VoD streams at this time.
• Once you are done with configuration, you can click the Test button to validate your
input for Live Streaming, Video on Demand and FTP Settings.
To create a VRR for use with an external server:
Go to VRR > VRRs.
1
In the ACTIONS list, click Add.
2
3 Click General Properties tab to configure the following setting:
Parameter
Template
Click Advanced Properties tab to configure the following setting:
4
Parameter
Enable External
Media Servers
To configure the rest of the settings, refer to
5
6 Click OK.
Description
Click Select and then select a Template that uses
MP4 or WMV as the Streaming Format.
Description
Select this option to support external media servers. You can:
• Select one or more media servers to which you can live
stream meetings.
• Select one or more FTP servers to which you can transfer
meeting recordings (VoD files) and view these recordings
as on demand streams later.
Note: You need to configure external servers from External
Servers > Media Servers first.
Using the RSS 4000 Admin UI
To define a VRR: on page 69.
79
