Polycom RSS 4000 User Manual page 139

Polycom, Inc.
Server Type
Server IP
Server Port
Specify whether to enable Live Streaming. If enabled, also configure the
4
following settings:
Parameter
Publishing Point
Name
User Name
Password
5 Specify whether to stream video on demand (VoD) from this server. If
enabled, click the Test button to verify the entered information.
Appendix C– Configuring External Servers
Select QuickTime Streaming Server.
Specify the QuickTime Streaming server IP
address.
Specifies the port that the RSS 4000 system uses
to send the encoded MP4 live streams to the
QuickTime Streaming server. By default, 554 is
assigned.
Note: Valid port values range from 1-65536. The
port number must be the same as set in the
corresponding external media server.
If a firewall sits between the RSS 4000 system
and the external server, make sure that rules are
set to allow the two-way communication
between the RSS 4000 system and the external
server.
Description
Specify a name for the publishing point. This
field is optional. If a name is set (the suffix must
be .sdp), a publish point with this name is created
in the QuickTime Streaming server; if not, the
Polycom RSS 4000 delivery proxy creates a
publishing point with random name.
Specify the user name to access the QuickTime
Streaming server.
This option is required when QuickTime
Streaming server authentication is enabled. The
User Name should be consistent with your input
in To configure the QuickTime Streaming server:
on page 130.
Specify the password to access the QuickTime
Streaming server.
This option is required when QuickTime
Streaming server authentication is enabled. The
Password should be consistent with your input in
To configure the QuickTime Streaming server:
on page 130.
131
