Polycom RSS 4000 User Manual page 21

Starting a Recording
Polycom, Inc.
The recording starts immediately if Recording Immediately is enabled in the selected
VRR.
For more information, see
To start recording by dialing the Polycom RSS 4000 system:
Enter the E.164 prefix or H.323 ID of the Polycom RSS 4000 system on the
1
remote control of an interoperable endpoint.
If your system or endpoint is not registered to the gatekeeper or to a SIP
server, call the system IP address instead.
Select Start Recording > Start using the remote control.
2
the recording is ongoing.
You can also dial in to a VRR directly to start recording by dialing one of the following:
• [RSS IP]##[VRR number]#
For example, if the RSS IP is 11.12.13.14, and the VRR number is 4096, dial
11.12.13.14##4096#.
• [RSS H.323 ID][VRR number]
For example, if the RSS H.323 ID is rss123, and the VRR number is 4096, dial
rss1234096.
For more information about recording using VRRs, refer to
page 72.
To register to Microsoft Lync Server 2010
1 Go to System Config > Signaling Settings > SIP.
2 Click Register to SIP Server.
Click Register to Microsoft Lync Server 2010.
3
Configure the following settings:
4
Parameter Description
SIP Server Specify the IP address, connection port, and domain name of the
SIP server for registration service.
Register User Specify the user name and password that authenticates the system
Information to the SIP Server.
Outbound Proxy For communication with the SIP server when the system is
Server configured on the internal network, an outbound proxy server is
required to implement traversal of the firewall or NAT. In this
case, you need to set the IP address and port number for the
outbound proxy server.
To define a VRR: on page 69.
Getting Started
indicates that
Predetermined VRR on
13
