Polycom RSS 4000 User Manual page 141

Polycom, Inc.
3 Install and configure an FTP server. The FTP server shares the
c:\WMpub\WMarchive directory. You need to grant the user at least the
Read, Write, and Create Directories authorities.
To configure the RSS 4000 system for work with the Windows Media server:
1 Go to External Servers > Media Servers.
On the ACTION panel, click Add.
2
Configure the following basic settings.
3
To enable Windows Media Server authentication, modify the properties as
the following:
Parameter
Server Name
Server Type
Server IP
Server Port
Specify whether to enable Live Streaming. If enabled, also configure the
4
following settings:
Appendix C– Configuring External Servers
Description
Specify the user name to access the Windows
Media Server.
Select Windows Media Server.
Specify the Windows Media Server IP address.
HTTP Server Port: 80 (default)
RTSP Server Port: 554 (default)
Note: Valid port values range from 1-65536. The
port number must be the same as set in the
corresponding external media server.
If a firewall sits between the RSS 4000 system
and the external server, make sure that rules are
set to allow the two-way communication
between the RSS 4000 system and the external
server.
133
