Live Streaming - Polycom RSS 4000 User Manual

Media Management

Live Streaming

Polycom, Inc.
using the remote control of an interoperable endpoint.
Quick code is not supported in SIP calls, or recordings created using multipoint VRRs.
To see a list of compatible endpoints, please refer to the Release Notes for the Polycom
support.polycom.com.
RSS 4000 8.5 on
To view the quick code of an archive:
Go to Media > Archives.
1
2 Double-click an archive.The quick code is displayed in the Properties
page of archives.
To play back archives using the quick code:
>> Dial using one of the following formats:
— If the system has been registered to a gatekeeper, dial [RSS E.164
prefix][Quick Code]#
For example, if the E.164 prefix of the Polycom RSS 4000 system is
1234 and the quick code of the file to be played back is 567890, dial
1234567890#
— If the system has not been registered to a gatekeeper, dial [RSS IP
address]##[Quick Code]#
For example, if the IP address of the Polycom RSS 4000 system is
10.1.2.3 and the quick code of the file to be played back is 567890, dial
10.1.2.3##567890#
If you are asked to enter the PIN code, enter the PIN code using the
remote control and then press #. To exit playing and return to the file
list during the playback, press the up arrow button of the remote
control.
• The quick code playback is available only in H.323 calls when playing back
archives that were not recorded with a multipoint VRR.
• If the bandwidth at which a user endpoint is connected with the Polycom RSS 4000
system is lower than the bandwidth originally used to create the archives, then the
videos cannot be played back successfully on that endpoint's screen.
The Polycom RSS 4000 system supports live streaming of video sources, such
as live video conference or dual stream sent by endpoints or MCUs with a
highest resolution of 720p and a maximum bandwidth of 4M. You can view
meeting videos and the second channel of dual stream in real time by
connecting to the Polycom RSS 4000 Admin UI or Viewer Portal directly
through network, without using endpoint devices. Those live streaming
videos are saved in the system.
Using the RSS 4000 Admin UI
