Polycom RSS 4000 User Manual page 133

Polycom, Inc.
Server Type
Server IP
Server Port
4 Specify whether to enable Live Streaming. If enabled, also configure the
following settings:
Parameter
Application Name
Publishing Point Name
User Name
Password
Specify whether to stream video on demand (VoD) from this server.
5
Appendix C– Configuring External Servers
Select Wowza Media Server.
Specify the Wowza server IP address.
Specifies the port that the RSS 4000 system uses
to send the encoded MP4 live streams to the
Wowza server. By default, 1935 is assigned.
Note: Valid port values range from 1-65536. The
port number must be the same as set in the
corresponding external media server.
If a firewall sits between the RSS 4000 system
and the external server, make sure that rules are
set to allow the two-way communication
between the RSS 4000 system and the external
server.
Description
Specify the name of the Wowza server
application to be used for the live streaming.
It should be consistent with the Wowza server
configuration. In this example, application name
is live.
Specify a name for the publishing point. This
field is optional.
If a name is set, a publish point with this name is
created in the Wowza server; If not set, the
Polycom RSS 4000 system delivery proxy
creates a publish point with random name.
Specify the user name to access the Wowza
media server. This option is required when
Wowza authentication is enabled. The User
Name should be consistent with your input in
configure the Wowza server:
Specify the password to access the Wowza media
server. This option is required when Wowza
authentication is enabled. The Password should
be consistent with your input in
Wowza server: on page 123.
To
on page 123.
To configure the
125
