[For Straight Slide Actuators]
Current
Position
Zone signal
output
Zone signal
output
Caution
Zone functions differ depending on the application version.
• For application version V0015 or earlier, zone output is not performed for the setting below;
Zone setting + ≤ zone setting –
• For application version V0016 or earlier, zone output is not performed for the setting below;
Zone setting + = zone setting –
56
Part 1 Specification
Set value
Zone setting + : 70mm
Zone setting - : 30mm
Set value
Zone setting + : 30mm
Zone setting - : 70mm
