(2) Examples of Queries/Responses
Queries are implemented by changing (writing) a 1-word register and thus the basic pattern is the same with all queries.
The only differences are the starting address and data. The following explanations use axis (0) or axis (12) in the
example.
[1] Write gateway control signals 0, 1
MON (bit 15 of control signal 0) is the only applicable control signal. Always turn this signal ON to enable the
applicable control.
Query
Field name
Header
Slave address
Function code
Starting address
Starting address
New data (data written) (upper)
New data (data written) (lower)
Error check
Trailer
Total bytes
Response
If the data has been changed (written) successfully, the response is the same as the query.
Actual Example
Sent Query:
Received Response:
RTU mode data
(8 bits)
None
3F H
06 H
(upper) F6 H
(lower) 00 H
80 H
00 H
(CRC) 16 bits
None
3F06F6008000DF5C
3F06F6008000DF5C
Data length
(bytes)
-
1 Fixed.
1
2 Address of gateway control signal 0 register
2
2 Based on calculation result
-
8
Part 1 Specification
Remarks
