The position table is explained using the screen of the PC software as an example.
(The display is different on the teaching pendant.)
Position Speed
Zone+
(1) No.
(2) Position
Position
* On the teaching pendant (RCM-T), this sign indicates that the position is specified in relative coordinates.
A : Absolute coordination specification (ABS)
I : Indicates the relative coordination specification (INC)
(3) Speed
Acceleration Deceleration
Acceleration
Zone-
/deceleration
mode
• A position data number is indicated.
• Input the target position to which to move the actuator [mm].
Absolute coordination specification: Input the distance from the actuator home.
Relative coordination specification: Constant pitch feed is assumed. The specified value
Absolute coordination specification: The target position is 5 mm from the home.
Relative coordination specification: The target position is 10 mm plus the current position.
Relative coordination specification: The target position is 10 mm minus the current position.
• Input the speed at which to move the actuator [mm/sec].
The default varies according to the actuator type.
Push Threshold
Command
Incremental
mode
represents a relative distance from the current position.
Position number
On the teaching pendant (CON-T),
this sign indicates that the position is
specified in relative coordinates.
