3. Execute buttons
Pressing these buttons perform specific operations.
Item select
Property
Create new file
Create new folder
Rename
Copy
Delete
Format
4. Directory path
The path to the drive, folder or file that is currently active is displayed.
5. Folder/file display
A list of drives, folders and files is displayed.
6. Close button
The crrent screen is closed, returning to the previous screen.
7. Directory Level buttons
From the currently displayed folder, moves either 1 directory up or 1 directory down.
Displays the information about the drive, folder and file
<Drive>
Displays the drive name, the file system, open memory, total memory and volume
name.
<Folder>
Displays folder name, creation date, and time of creation.
<Data File>
Displays the model name, the sample interval, the data points and trigger time.
Creates a file for data recording or a file for setting conditions.
Opens the file creation character entry screen and creates a file under the current
displayed drive or folder with the name entered.
For how to enter characters, see "(2) Enter a character" on page 3-26.
Creates a folder.
Opens the folder creation character entry screen and creates a folder under the
current displayed drive or folder with the name entered.
For how to enter characters, see "(2) Enter a character" on page 3-26.
In File operation screen, change the name of the selected file or folder.
When this button is touched, already entered name is display. Change this name to
new one.
For how to enter characters, see "(2) Enter a character" on page 3-26.
* The file will have the extension. Do not change the extension.
Copies the selected file/folder to the specified copy destination (drive or folder).
Use the pre-select buttion to select the original and the copy destination.
Deletes the selected files/folders.
Formats the selected drive using set contents.
Use the pre-select button to select the type of format.
Description
CHAPTER 3 Measure and Set
3-29
