CHAPTER 3 Measure and Set
HOME
Machine settings
3-14
Data settings
Record settings
Marker settings
Backup settings
Output settings (* Displayed when the Voltage Output Module is installed.)
Trigger/Alarm settings
Start source
Level settings
Logic settings
Alarm port number
Date setting
Weekly settings
Time settings
Stop source
Level settings
Logic settings
Alarm port number
Date setting
Weekly settings
Time settings
Repeat
Repeat interval
Pretrigger points
Alarm hold
Burnout alarm
Sample interval
AC Line filter
Destination
Capture point
Auto save
Ring capture
Ring capture
Data points
Data save
File name
Name type
File type
Marker (markers 1 to 8)
Marking (each marker)
Backup intervals
Backup destination
Save folder
DCO module settings (To Voltage Output Module (GL7-DCO)
in each amplifier module (G))
Start / Stop synchronization
Repeat output
Emergency stop alarm CH output
Output level at the time of Stop
Data load
Start output
Date
Time
Day (Sunday to Saturday)
Time
Time
Date
Time
Day (Sunday to Saturday)
Time
Time
Symbols References
P.3-48
P.3-64
