(22) Cursor position

Moves the cursor to a specified location.
<If cursor movement is positional>
(22)-1 (22)-2
(22)-10 (22)-11
Item select
(22)-1 Move to first
(22)-2 Move to center
(22)-3 Move to last
(22)-4 Move to trigger
(22)-5 Move to selected position
(22)-6
(22)-7
(22)-8 Move
(22)-9 Cursor sync
(22)-10 A-cursor
(22)-11 B-cursor
(22)-12 Call other cursor
(22)-1 Move to first
Upon execution, the currently selected cursor (A or B) moves to the top data.
Cursor A Cursor B
(22)-2 Move to center
Upon execution, the currently selected cursor (A or B) moves to the center data.
(22)-3 (22)-4
(22)-12
[Position] Move to
[Time] Move at
<If cursor movement is time based>
(22)-1 (22)-2
(22)-8
(22)-5
(22)-6
(22)-9
(22)-10 (22)-11
Execute
Execute
Execute
Execute
Position, Time
0 to Relative position
Date/time, start of data to end of data
Execute
Off, On
Execute
Execute
Execute
CHAPTER 3 Measure and Set
(22)-3 (22)-4
(22)-12
Examples of item
(22)-8
(22)-5
(22)-7
(22)-9
3-137
