CHAPTER 4 Specification

4.1 Standard Specifications

Standard Specifications
Item
Number of Amplifier
Modules
External input/output
Alarm input/output
PC I/F
Internal memory device
External memory device
Backup function
Clock accuracy (23ºC
environment)
Synchronization
between measurement
modules
Time base accuracy
Usage environment
Withstand voltage
Insulation resistance
Power supply
Power consumption
External dimension
(approx.) [W × H × D]
Weight (approx.)
Others
4-2
Max. 10 modules
* The DC strain module can be installed up to 8 modules.
* Function Modules like the Display Module and the SSD Module are not included in the
10 Modules mentioned above.
* The Logic/Pulse amplifier can be set to either logical amplifier or pulse amplifier. The
pulse amplifier can only be set for up to 2 modules (16ch/1 module).
Start/Stop input, External trigger input, External sampling input, Trigger output.
* When using the external input/output function, the I/O cable B-513 (optional) for GL
series is required.
10ch
* The Alarm Module is a separate module from the main module.
Ethernet (10BASE-T/100BASE-TX), USB2.0 (compatible with high-speed), standard-
included
Built-in flash memory: approx. 2GB or more
* The built-in RAM is equipped with standard in each Amplifier Module, which can be
stored 2,000,000 data. Synchronization function is available in GL-Connection only.
SD card (SDHC equivalent, maximum approx. 32GB) slot standard-included
Setting Conditions: EEPROM/Clock: Lithium secondary battery
±0.002% (Lunar equation: approx. 50 seconds)
With Start and Trigger synchronizing functions
* When using the synchronizing function, the optional coaxial cable B-559 is required.
The synchronizing function is available in the GL-Connection only.
±100ppm (23ºC±2ºC)
0 to 45ºC, 5 to 85% R.H.
Between AC power and housing: 1500 VAC at 1 minute
Between AC power and housing: 500 VDC at 20MΩ or more
AC input: 100 to 240 V AC/50 to 60Hz
85 VA
Main modle: 193 × 141 × 160 mm (not including protruding parts)
Alarm Module: 30 × 136 × 145 mm (not including protruding parts)
Main modle: 2.2 kg
Alarm Module: 350 g
Vibration proof: Automobile parts Type 1 Class A equivalent
Description
