CHAPTER 2 Checks and Preparation
Precautions to install SSD Module
The SSD Module is used by installing it on the main module together with other measuring modules.
The SSD module is installed in the same way as other Measuring Amplifier modules, but please make sure
to connect it to the GL7000.
< Example of installing>
Alarm Module
SSD Module
Voltage Module
GL7000Main Module
2-25
