CHAPTER 3 Measure and Set

(27) Output settings (DCO module settings)

Set the analog voltage output to the equipment to be received.
("Home" "GL7000 setting" "Data settings"
("Home" "GL7000 setting"
<Voltage Output Module (GL7-DCO)>
For the setting procedure for this module, refer to (4) Output settings in "3.6 Settings menu".
(The number in the following figure is expressed in the same number as the number of (4) Output settings in
"3.6 Settings menu".)
<Output settings
(4)-1-(o)
<When using Sine wave, Triangle wave, Ramp wave>
(4)-1 (a) Output source
(b) File name
(c) Output sampling interval
(d) Data points
(e) Read from the output source
3-144
"DCO module settings")
DCO module settings>
(4)-1-(p)
Item select
"Output settings" "DCO module settings")
(4)-1-(a)
(4)-1-(b)
(4)-1-(c)
(4)-1-(e)
(4)-1-(d)
<When using Pulse wave>
(4)-1-(f)
(4)-1-(g)
(4)-1-(h)
(4)-1-( i )
(4)-1-( j )
(4)-1-(m)
(4)-1-(n)
Examples of item
Built-in RAM, File
File selection
10ms (100kS/s), 20ms (50kS/s), 50ms (20kS/s), 100ms (10kS/s),
200ms (5kS/s), 500ms (2kS/s), 1ms (1kS/s), 2ms (500S/s),
5ms (200S/s), 10ms (100S/s), 20ms (50S/s), 50ms (20S/s),
100ms (10S/s), 125ms (8S/s), 200ms (5S/s), 250ms (4S/s),
500ms (2S/s), 1s (1S/s), 2s, 5s, 10s, 20s, 30s, 1min, 2min, 5min,
10min, 20min, 30min, 1h
1 to 128,000,000 points
Reading the file data conditions
(4)-1-(k)
(4)-1-( l )
