(1)-6 Ring capture
("Home" "Machine"
Item select
(1) Ring capture
(2) Data points
(1) Ring capture
Sets the Ring recording function to On or Off.
(2) Data points
When the ring function is On, the ring point of 1 file is specified.
•
Ring capture actions (When the recording destination is the built-in RAM)
If the recording destination is the built-in RAM, the memory is connected in a ring form, and when it
exceeds the specified number of the data points, data is deleted starting with the oldest data.
When the main module stops, the data on the number of
"Data" "Capture" "Ring capture settings")
Off, On
1,000 to 2,000,000
data set in Number of recording points remain.
2,000,000 points
(1) Ring capture
(2) Data points
Examples of item
CHAPTER 3 Measure and Set
3-53
