CHAPTER 3 Measure and Set
(4)-1-(e) Read from the output source
The sampling interval and the data points are read from the data in the output source (built-in RAM or file)
set in (4)-1-(a), and then they are set to the output sampling interval in (4)-1-(c) and the data points in (4)-1-(d).
When you set to Data file, please use the GL7000 after checking the followings. (GBD file data only is available.)
•
If the data has not been saved to the built-in RAM or the specified file does not exist, the corresponding output CH will
be 0V data.
•
If specifying the CH that does not exist in the data file, the corresponding output CH will be 0V data.
•
If specifying the CH recorded when "Temperature / Humidity and Logic / Pulse" are input in the data file, the
corresponding output CH will be 0V data.
•
In the data output sampling interval, the data is output with the output sampling interval set in "(4)-1-(c) Output
sampling interval", regardless of the sampling interval recorded in the data file.
(4)-1-(f) Settings (Data type)
Select the data type and set the output conditions. The data in the data file is output within the set output
range, regardless of the full scale range of the file.
The following table shows the settings and setting range.
Settings
Data type
Data file
DC
Sine wave
Triangle wave
Ramp wave
Pulse wave
Sine wave
Offset
Ramp wave
Offset
3-60
Amplitude Offset
0 to 20V ±10V
NG NG
OK OK
OK OK
OK OK
OK OK
OK OK
Cycle
Amplitude
Phase
Cycle
Amplitude
Phase
Frequency Phase
0 to 10kHz -360 to +360deg.
NG NG
NG NG
OK OK
OK OK
OK OK
OK NG
Triangle wave
Cycle
Amplitude
Offset Phase
Pulse wave
Cycle (T)
Amplitude
Offset
t Delay
Delay Duty
0 to 100sec. 0 to 100%
NG NG
NG NG
NG NG
NG NG
NG NG
OK OK
Duty ratio =
t
T
