DATA PLATFORM
GL7000　
Thank you for purchasing Graphtec DATA PLATFORM GL7000. The Quick Start
Guide is to assist you with the basic operations. For detailed instructions, please
refer to the instruction manual on the CD-ROM (PDF format) enclosed.
Check the outer casing first
Check the exterior of the unit to ensure that there are no cracks, defects or
any other damages before use.
Accessories
・Alarm Module:
・Quick start guide:
・CD-ROM:
・Face cover:
・AC power cord :
Setting and confirming the AC line frequency
(When using Voltage/Temperature Module(GL7-M)
In OTHER menu, set AC line frequency to (50Hz or 60Hz) to reduce noise
level.
Quick Start Guide
1
1
1
1
1
GL7000-UM-855

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Data Platform GL7000 and is the answer not in the manual?

Questions and answers

Related Manuals for GRAPHTEC Data Platform GL7000

Summary of Contents for GRAPHTEC Data Platform GL7000

  • Page 1 GL7000　 Quick Start Guide GL7000-UM-855 Thank you for purchasing Graphtec DATA PLATFORM GL7000. The Quick Start Guide is to assist you with the basic operations. For detailed instructions, please refer to the instruction manual on the CD-ROM (PDF format) enclosed.

  • Page 2: Table Of Contents

    Table of Contents 1. GL7000 operating guide ..............................4 1-1. CE marked equipment guide ..........................4 1-2. Location recommendation ...........................4 1-3. Warning for maximum input voltage ........................4 1-4. Warning for module installation/removal......................4 1-5. Installation space recommendation ........................4 1-6. Warm-up ................................4 2. Part Names ..................................5 2-1.
  • Page 3 6-11. To Stop GL-Connection ...........................16 6-12. Replay on GL-Connection ..........................17 7. Display Module (GL7-DISP) ..............................18 7-1. Screen operating instructions ...........................18 7-2. Touch-screen operations ..........................19 7-2-1. Pressing a button .............................19 7-2-2. Selecting an item .............................19 7-2-3. Moving the slide bar ..........................19 7-3.

  • Page 4: Gl7000 Operating Guide

    1. GL7000 operating guide 1-1. CE marked equipment guide GL7000 conforms to the EN61326-1 Class A based on the EMC Directive (2014/30/EU)Additionally, it conforms to the EN61010-1:2010 3rd based on the LV Directive (2014/35/EU). The instrument meets both the standards. When operating the instrument, follow the safety guide in the instructions manual (PDF) found on the attached CD-ROM.

  • Page 5: Part Names

    2. Part Names 2-1. Front view Alarm Module Main Module Alarm output terminals Monitor out connector SD card slot Power switch Action status LED USB I/F terminal Synchronous connection terminal 　・POWER REMOTE terminal 　・START LAN I/F terminal 　・ACCESS 2-2. Side view Cooling fan Name plate AC power connector...

  • Page 6: Voltage Module (Optional)

    Available optional modules. 2-3. Voltage Module (optional) Cooling fan Module connector Power LED Analog signal input terminal 2-4. Display Module (optional) Module connector Operation key (For direct connection) Monitor Monitor connector (For connecting cable) 2-5. SSD Module (optional) Cooling fan Module connector Access lamp...

  • Page 7: Set-Up Position

    3. Set-up position To use GL7000, use it in an upright position as shown below. 3-1. Standard main module only 3-2. Installing the Display Module (optional) For details on installing the optional Display Module, see the instruction manual for the Module. <Install to GL7000 >...

  • Page 8: How To Power The Gl7000

    4. How to power the GL7000 4-1. Connecting the AC power cord Insert the AC power cable into the GL7000 and the other end into an electrical outlet. *AC power cord may differ depending on your country designation. 4-2. Connecting to the GND terminal Use the GND terminal when the power cord cannot be grounded and when the GND level is shared with other equipment.

  • Page 9: How To Install The Modules To The Gl7000

    The maximum connection of every type of Amplifier Module is 10 modules (112ch maximum). For external memory installation, an SD card slot (SDHC equivalent, maximum approx. 32GB) is included as standard equipment (* SD cards not provided by Graphtec). An SSD 128GB is available as an option. (However, 1 file cannot exceed 4GB)

  • Page 10: Gl-Connection Software

    6. GL-Connection software The GL-Connection is a PC software for managing and measuring on the GL7000. The GL-Connection (included as standard) will do the following: ・ Operate the GL7000 (settings reference, recording start, recording stop etc.) ・ Record real time data (Real time data recording is possible at 1 ms at the fastest). * ・...

  • Page 11: Connecting Gl7000 And Pc

    The instrument has USB and LAN interface settings. Settings can be found on the Config program included in the installation software. From the Windows select “Start” → ”Programs (All Programs)” → ”Graphtec” → ”GL-Connection” → ”GLConfig” to launch the software.

  • Page 12: Starting The Gl-Connection

    6-6. Starting the GL-Connection To “Start” the software on the Windows OS, select “All Programs” → Graphtec → GL- Connection → GL-Connection to launch the GL-Connection software. LANGUAGE SELECTION is displayed on the first screen. Select the desired language.

  • Page 13: Connecting The Gl-Connection

    6-7. Connecting the GL-Connection Start the GL-Connection. When GL7000 and PC are correctly linked, and when the power to the GL7000 is turned on, your PC will automactically recognize the GL7000 and display the GL7000 icon. If the icon is not displayed, see section “6.5 GL7000 Interface Settings.”...

  • Page 14: Description Of Main Screen In Gl-Connection

    6-8. Description of MAIN screen in GL-Connection Press the screen change button on the control panel to change to the main screen. The connection screen and the main screen can be changed at any time. 1. Help window 2. Tab 3.

  • Page 15: Setting Screen In Gl-Connection

    6-9. SETTING screen in GL-Connection Push the setting button on the control panel to open the SETTING screen. GL7000 setting items are displayed. 6-9-1. Main menu The menu screen allows access to various main module settings. By pressing the displayed Amplifier Module, each module’s setting screen comes up.

  • Page 16: Recording With Gl-Connection Software

    6-10. Recording with GL-Connection software 6-10-1. Record start button Press the record start/stop button on the control panel to start recording. The recording method will differ depending on whether it is recorded on the built-in RAM or on the internal or external disks. Built-in RAM Records to the built-in RAM of the main module.

  • Page 17: Replay On Gl-Connection

    6-12. Replay on GL-Connection Data files recorded on the PC and main module data saved on the GL7000 can be replayed and reviewed. For data playback, any signal level value can be displayed by using the cursor, and data can be searched by specified time. Press [Control Panel] >...

  • Page 18: Display Module (Gl7-Disp)

    7. Display Module (GL7-DISP) Use the optional Display Module, to allow stand-alone measurement. This chapter explains operation using the Display Module. 7-1. Screen operating instructions 4. Alarm display １. Simple message 2. TIME/DIV 3. Status lamp 5. Status mark ﾌﾘｰﾗﾝﾆﾝｸﾞ 6.

  • Page 19: Touch-Screen Operations

    7-2. Touch-screen operations The display option is equipped with a touch-screen function. Following are the basic operations for using the Touch-screen feature. Example: change the sample interval. 7-2-1. Pressing a button Since this is a capacitive touch-screen, mechanical device such as a pen or pencil will not work. Remove gloves etc.

  • Page 20: Description Of The Operation Keys

    7-3. Description of the operation keys 6.QUIT 1. HOME 5.ENTER 2. Direction key 4.LOCK 3.START/STOP (USB DRIVE) Name Description HOME Press the main key to return to the home menu. Direction key Used for item selection during setup and cursor movement during playback.

  • Page 21: Description Of The Home Screen

    7-4. Description of the HOME screen Press “Home” on the screen or the HOME key, to display the home menu. (Chart below) Press the icons to perform the following settings. Here we explain the icons displayed on the home menu. 1.

  • Page 22: Specifications

    8. Specifications 8-1. Standard specifications Items Description The number of Amplifier Maximum 10 modules Modules installed * The Logic/Pulse Amplifier Module can be set to select logic amplifier or pulse amplifier, but the pulse amplifier can only be set for up to 2modules (16ch/1 module). External input/output Start/Stop input, external trigger input, external sample input, trigger output, auto balance input, busy output per 1ch.
  • Page 23 Items Description External sampling input Maximum input frequency for built-in RAM recording: 1MHz SSD recording (optional): 1 kHz Build-in flash recording: 1 kHz SD card recording: 1 kHz Temporal error: The fastest sampling interval for every Amplifier Module or less. * For every amplifier's fastest sampling interval, see the instruction manual on the CD-ROM.
  • Page 24 ●Specifications are subject to change without notice. GL7000 Quick Start Guide (GL7000-UM-855) November 1, 2018　1st edition-01 GRAPHTEC CORPORATION...
