CHAPTER 3 Measure and Set
(4) Output settings
This is used to output the analog voltage to the equipment to be received.
("Home" "GL7000 setting" "Data settings"
<Output settings>
(4)-7
<When using Sine wave, Triangle wave, Ramp wave>
(4)-1
(a)
DCO
module
(b)
(c)
(d)
(e)
(f)
(g)
(h)
(i)
(j)
(k)
(l)
(m)
(n)
(o)
(p)
(4)-2
Start / Stop synchronization
3-58
(4)-6
Item select
Output source
File name
Output sampling interval
Data points
Read from the output
source
Setting
Data type
(ALL,
1CH to
Amplitude
8CH)
Offset
Frequency
Phase
Delay
Duty
Output rage
Filter
Data load
Start output
"Output settings")
<Output settings
(4)-1
(4)-2
(4)-3
(4)-4
(4)-5
(4)-1-(o)
<When using Pulse wave>
(4)-1-(f)
(4)-1-(g)
(4)-1-(h)
(4)-1-( i )
(4)-1-( j )
(4)-1-(m)
(4)-1-(n)
Examples of item
Built-in RAM, File
File selection
10ms (100kS/s), 20ms (50kS/s), 50ms (20kS/s), 100ms (10kS/s),
200ms (5kS/s), 500ms (2kS/s), 1ms (1kS/s), 2ms (500S/s),
5ms (200S/s), 10ms (100S/s), 20ms (50S/s), 50ms (20S/s),
100ms (10S/s), 125ms (8S/s), 200ms (5S/s), 250ms (4S/s),
500ms (2S/s), 1s (1S/s), 2s, 5s, 10s, 20s, 30s, 1min, 2min, 5min,
10min, 20min, 30min, 1h
1 to 128,000,000 points
Reading the file data conditions
Off, Data file, DC, Sine wave, Triangle wave, Ramp wave, Pulse
wave
0.000 to +20.000V
-10.000 to +10.000V
0.00 to 10,000.00Hz
-360.0 to +360.0deg.
0.00000 to 100.00000sec.
0.00 to 100.00%
1, 2, 5, 10V
Off, Line, 5 / 50 / 500Hz, 5 / 50kHz
Reading the analog voltage output data and conditions
Analog voltage output start / output stop
Off, On
DCO module settings>
(4)-1-(p)
(4)-1-(a)
(4)-1-(b)
(4)-1-(c)
(4)-1-(e)
(4)-1-(d)
(4)-1-(k)
(4)-1-( l )
