(8) FTP server settings

Sets information concerning the connected FTP server for backup, etc.
("Home" "Machine" "Network settings"
Item select
(8)-1 FTP Server
(8)-2 User name
(8)-3 Pass word
(8)-4 Port number
(8)-5 PASV Mode
(8)-6 Connection test
(8)-1 FTP Server
Enter the FTP server domain name or IP address.
(8)-2 User name
Enter the FTP account username.
(8)-3 Pass word
Enter the FTP account password.
(8)-4 Port number
Enter the port number used with FTP. Normally this number is 21.
(8)-5 PASV Mode
Set the passive mode.
Item select
Off Set when communicating with the FTP server in a normal network environment.
On Set when communicating with an external firewall in a firewalled network environment.
"FTP Server settings")
(8)-1
(8)-2
(8)-3
(8)-4
(8)-5
(8)-6
Text input
Text input
Text input
0 to 65535
Off, On
Execute
Description
Examples of item
CHAPTER 3 Measure and Set
3-71
