(4)-2 Start/Stop synchronization
When the Start / Stop synchronization is set to On, the analog voltage output is started at the same time as
the GL7000 start, and the output is stopped at the same time as the GL7000 stop (free-running state).
When the Start / Stop synchronization is set to Off, it is possible to operate the start output / stop output
described in "(4)-1-(p) or (4)-7 Start output", regardless of the start / stop of GL7000.
The analog voltage output at the time of stop conforms to the conditions set in "(4)-5 Output level at the time of Stop".
* When the Output level at the time of Stop is set to "Retain", the voltage value at the time of stop is output.
(4)-3 Repeat output
When the Repeat output is set to On, the analog voltage is repeatedly output until the stop operation is
exeduted.
(4)-4 Emergency stop alarm CH output
When the alarm output CH is specified to the alarm module in the GL7000, the analog voltage output is
forcibly stopped when the alarm occurs.
(4)-5 Output level at the time of Stop
The analog voltage output conditions when the output is stopped can be set.
0V: The analog voltage output is 0V.
Retain: The voltage value at the time of stop continues to output as the analog voltage output.
•
When the analog voltage is output after setting to Retain, please take care in handling the equipment to be received.
•
To turn the analog voltage output to 0V, execute the re-load data.
(4)-6 Data load
This data load is linked with the operation described in "(4)-1-(o) Data load". So it is possible for both
operations.
(4)-7 Start output
This Start output is linked with the operation of "(4)-1-(p) Start output". So it is possible to execute for both
operations.
