CHAPTER 4 Specification
4.5 Accessory/Option Specifications
Control software (GL-Connection)
Item
OS supported
Functions
Number of main module
connected
Number of channels per one
main module
Max. number of channels
Setting range
Captured data
Display
Display modes
File conversion
Mailing functionality
Statistics display
Search function
Screen lock function
Data output function
*1: There are limitations to real-time transfer. The more the number of channels increases, the more limited the real-time
display of the sampling interval becomes.
The number of DC strain modules that can be installed is up to 8 modules.
Standard accessories
Item
Alarm Output Module
Quick Start Guide
CD-ROM
Face cover
AC cable
4-18
Windows 8 (32/64-Bit) / Windows 7 (32/64-Bit) (StarterEdition not available) /
Vista (32/64-Bit) / XP (SP2 or higher)
Controlling main module, real-time recording data, conversion, data replay
Max. 10 modules* 1
Max. 112 channels*
1
1120 channels* 1
Amplifier settings, recording settings, trigger/alarm settings, report settings,
others
Built-in RAM (binary)
SSD (CSV, binary)
Built-in flash memory (CSV, binary)
SD card (CSV, binary)
* For CSV data, the corresponding high speed sampling interval will be up to 1
msec. (For 1CH)
* The recorded data cannot save the built-in RAM or SSD in real time. After
recorded, the data is saved in PC while replaying on the GL7000.
Analog waveforms, logic waveforms, pulse waveforms, digital values
Y-T View (displayed in the digital value), X-Y View (in real time), FFT View, Cursor
Information View, Recorded Data View, Alarm Information View
* Digital display can be attained by maximizing the digital part of the Y-T.
Between cursors, All data, Thinning function
A mail is sent to a specified address when an alarm occurs
During recording: maximum value, minimum value, Average value, peak value
During replaying: maximum value, minimum value, Average value, peak value,
RMS
Level search : Searches at any channel or any level.
Alarm search : Searches at any channel or any alarm.
Time move : Move to first, Move to last, Move to center, Move to trigger, Move
to absolute time, Move to Relative time, Move to data points, Move
to mark.
Locks the operation (with arbitrary password setting function)
PC file data (GBD/CSV), Module file data (GBD), DC, Sinusoidal wave, Triangular
wave, Ramp wave, Pulse wave
* GL-Connection version 1.40 or later
* When the Voltage Output Module is installed, this function is available
This is installed in the main module at shipping.
GL7000-UM-85X
User's Manual (PDF), Application software
This is installed in the main module at shipping.
Description
Description Quantity
1
1
1
1
1
