CHAPTER 1 General Description

1.1 Overvie

The GL7000 is a module-expanding, high speed, multi-function, multi-channel DATA PLATFORM.
A maximum of 10 Amplifier Modules can be expanded, and expansion of an SSD Module and a Display
Module makes it suitable for all sorts of needs.
In addition to being able record measuring data on the built-in RAM, it also comes equipped with a large capacity
flash memory. Since recording can be done to an SD card, transferring data to the PC when offline is easy.
For the PC interface, as USB and Ethernet is included as standard, system configuration according to use is
possible. As the Ethernet function is equipped with both a WEB server and an FTP server function, remote
supervision and data transfer are also possible.

1.2 Features

Input
•
In compliance with the diversity of the objects to be measured, an Amplifier Module where the amplifier can
be selected has been adopted.
Display and operations
•
In compliance with the diversity of the objects to be measured, an Amplifier Module where the amplifier can
be selected has been introduced.
•
It comes equipped with a high resolution 5.7" TFT color liquid crystal display.
•
A capacitive touch-screen is adopted, and because of the easy-to-understand menu configuration
operations can easily be carried out.
•
By separately placing keys on the touch-screen, we've made it possible to carry out operations in
environments where the touch-screen can't be used, such as when wearing gloves.
*: For when the optional Display Module is installed
Recording
•
Data can be saved directly to the built-in flash memory and to an SD card.
•
Data recorded in the built-in flash memory is retained even if the power is turned off.
•
Because disk image can be used for the built-in flash memory, multiple data can be saved.
•
High speed recording can be done by recording to the built-in RAM. After confirming the recorded data, if
necessary, it can be saved to the built-in flash or an SD card.
•
Because it comes equipped with a ring recording function, even if doing long time recordings, the latest
data always remains.
•
When recording to the built-in RAM, built-in flash memory, or an SD card, even if the number of modules is
increased, the sampling rate will not go down.
•
The SSD Module (optional) is provided. With high speed, large quantity (1 file of maximum 2GB) data can
be recorded. (The sampling rate is restricted according to the number of connected modules.)
Data Control & Processing
•
The application software provided lets you set conditions and monitor data on a computer.
•
The USB drive mode function enables the main module's flash memory to be recognized as an external
drive by your PC. (Connect the main module to your PC and turn on the power supply to the main module
while holding down the [START] key.)
•
Captured data can be read from the application software to files and displayed for processing.
•
Data can be transferred off-line to a computer using USB memory.
•
Depending on the WEB Server function, remote management and supervision can be possible without
using the dedicated software.
•
With the FTP server function, you can operate the built-in flash memory and SD card on the PC.
•
With the FTP client function, you can create a backup of the measured data to the FTP server.
1-2
