CHAPTER 3 Measure and Set
(1)-5 Auto save
Sets the auto-saved function for the built-in RAM. This can only be set when RAM is selected to be recorded to.
("Home" "Machine" "Data" "Capture" "Auto save")
Item select
(1) Auto save
(2) File name
(3) Name type
(1) Auto save
Item select
Off
On
(2) File name
Specifies the recording destination folder and file name. Refer to "(3) File operations" on page 3-28 on
how to set a file.
(3) Naming metho
Sets how data files are named.
Auto
User
Serial number : A consecutive number is attached to the optionally input file name to create the file name.
* If a file with the same name already exists, to avoid overwriting _CP* is attached to the end of the file
name where the * represents a number.
<Ex.>: TEST_CP1.GBD
3-52
Off, On
Recording destination folder name or file name
Auto, User, Serial number
Auto-save is not activated. Data is deleted if the power is turned off or the next recording is
performed. When wanting to save recoded data, please save data after replay (refer to "(18) Data
Save" on page 3-130).
Auto-save is done. Data recorded on the built-in RAM is saved on the built-in flash memory, SD card
or the expanded SSD.
When speeding up the sample interval or increasing the number of recorded data, even if recording
to the built-in RAM has been finished, auto-save may not be finished. At such a time, it is not
possible to perform the next recording using the Start/Stop key until the auto-save has finished.
: Files are automatically named.
<Ex>: 20120101-123456.GBD
The numeric part .... The day the file was created
GBD . ....................... Data format, GBD (Binary data), CSV (Text format)
: Data is recorded to a user-input file name.
<Ex>: When the file name is "TEST"
First: TEST_SER1.GBD, Second: TEST_SER2.GBD, Third: TEST_SER1.GBD
(1) Auto save
(2) File name
(3) Name type
Examples of item
Examples of item
* E.g. 2012-01-01, 12:34:56
