CHAPTER 3 Measure and Set
(15)-6, 7 Caic. settings
2 statistics calculations can be executed on the GL7000.
Here the statistics calculation contents is set.
<Sample of the statistical calculation>
Item select
Off
Average
Max
Min
Prak
•
The result of the calculation is displayed on the Digital + Statistical Calculation screen in the logger display mode.
•
Calculation is started from when the power is turned on, and is cleared by pressing the QUIT key or by pressing the
Start key to start measurements.
•
Realtime statistics calculation is usabl when the sampling rate is slower than 100ms. When the sampling rate is faster
than 100ms, use the statistics calculation of the cursor functions after replaying recorded data.
3-118
Calculation process was not carried out.
During recording, the data simple addition average is displayed on the screen.
During recording, the maximum value of the data is displayed on the screen.
During recording, the minimum value the data is displayed on the screen.
During recording, the peak value of the data is displayed on the screen.
Description
