CHAPTER 4 Specification

Logic/Pulse Amplifier Module (Logic/Pulse) (GL7-L/P: optional)

Item
Number of input channels
Input terminal shape
Input method
Sampling interval
Built-in RAM
Functions
Mode
Revolve mode
Counts mode
Instant mode
Maximum input
frequency
Maximum number of
counts
Input specifications
Filter
External dimensions
(approx.) [W × D × H]
Weight (approx.)
4-12
16 channels/1 module
Dedicated connector (1 group per 4-ch)
Non-isolated, All-ch insulation, simultaneous sampling, unbalanced input
Logic: 1 μsec fastest
Pulse: 100 μsec fastest
2,000,000 data
Logic/Pulse
* Switching logic/pulse for each unit
The maximum use of the Logic function is 7 modules (112ch).
The maximum use of the Pulse function is 2 modules (32ch).
The maximum number of connections for each type of amplifier module to the GL7000
is up to 10 modules (112ch maximum).
Pulse : Rotation/Accumulating/Instant
Function : This mode counts the pulses for every sampling interval, and then converts
them to the RPM.
Span : 50, 500, 5000, 50 k, 500 k, 5 M, 50 M, 500 M .RPM/F.S.
Function : Mode for displaying the number of pulses accumulated for every sample
interval from the beginning of the recording.
Span : 50, 500, 5000, 50 k, 500 k, 5 M, 50 M, 500 M C/F.S.
Function : Mode for displaying the pulse count for every sampling interval. The
pulse count is reset for every sampling interval.
Span : 50, 500, 5000, 50 k, 500 k, 5 M, 50 M, 500 M C/F.S.
1 MHz
15 MC (24-bit counter)
Max. input voltage : 0 to +24 V (single-ended ground input)
Input signal : Non-voltage contact (a contact, b contact, NO, NC), Open
collector, Voltage input
Input threshold voltage : approx. +2.5 V
Hysteresis : approx. 0.5 V (approx. +2.5 V to +3 V)
OFF, ON (50 Hz, approx. –3 dB)
49.2 × 136 × 160 mm (Not including protruding parts)
700 g
Description
