Internal memory devices

Item
Memory capacity
Memory contents
*1: SSD Module (sold separately), GL7-SSD (optional) are required.
There is a limit to the highest sampling rate can be set for the number of modules to be used.
When setting the sampling interval to 1 μs or 2 μs, there is a limit to the number of pulse input channels. (For details,
see "(1)-1 Sampling Interval" in page 3-49.)

PC I/F

Item
Interface types
Software functions
Ethernet functions
(10BASE-T/100BASE-TX)
USB functions
Real-time data transfer
speed* 2
*1: SSD Module (sold separately), GL7-SSD (optional) are required.
*2: This depends on the number of transferred CH.
Built-in RAM: SD-RAM, 2,000,000 data (equipped with each Amplifier Module)
SSD* 1 : approx. 64GB (However, one file must be 2GB at the maximum)
Built-in flash memory: Flash memory, 2GB or more (However, one file must be 2GB at
the maximum.)
SD card: Compatible with SDHC, maximum approx. 32GB (However, one file must be
2GB at the maximum)
* Depending on the recording destination there is a limit to the sampling interval.
Built-in RAM: Measured data
SSD* 1 : Measured data, main module setting Conditions, Screen copy
Built-in flash memory: Measured data, main module setting Conditions, Screen copy
SD card: Measured data, main module setting Conditions, Screen copy
Ethernet (10BASE-T/100BASE-TX)
USB (High-speed)
Data transfer to the PC (real-time memory)
PC control of the main module
Web server functions: Displays the screen images of main module
FTP server functions: SSD*
SD card memory.
FTP client functions: Backup captured data to FTP server
NTP client functions: Time synchronization with the NTP server.
DHCP client functions: IP address automatic acquisition
USB drive mode: SSD* 1 , Built-in flash memory, Transfers and deletes of files from the
SD card memory.
* By flipping the machine slide switch, or turning on the power while pressing the [Start/
Stop] key on the Display Module, it goes into USB Drive Mode.
1 msec/10ch fastest
Description
Description
1 , Built-in flash memory, Transfers and deletes files from the
CHAPTER 4 Specification
4-3
